The main technical parameters

Model	Power supply	Vacuum fan power	Compaction frequency	Machine weigh	Dimensions in mm (length*width*height)
JCDB64	380V  50HZ  16.5KW	22KW	10T/M	2T	3500*2100*3950

Note: This machine can be customized to other sizes.

Product introduction:

The JCDB dust collection cake machine is suitable for the leather scraps collection of buffing machine, dusting machine, and other machines, meanwhile, it can effectively control leather scraps. It can greatly improve the working environment quality during the leather production, leather buffing, and dust removing, facilitates to recycle leather scraps, and is the necessary equipment for building environmental protection enterprise.

Features of the product:

1. The dust collection cake machine is equipped with a specially-made air blowing system. Its inlet is connected to the buffing machine and the dust removing machine through pipeline, and through his pipeline, the scraps produced in production can be conveyed to the dust collection cake machine.

2. Rotate the sweeper to collect the scraps into the inlet of the cake machine.

3. Its piston is driven by a hydraulic system, through which the scraps can be pressed into high-density blocks with the diameter of 90mm.
